OptiCyl EN-CY02-H Hanging
Model code EN-CY02-H
Hanging version of the OptiCyl surface cylinder, for hospitality, retail, premium residential and office spaces. Taller AL6063 aluminium bodies are supplied with a 1.5 m hanging canopy — a single current-carrying suspension wire with a ceiling plate — so each cylinder drops cleanly to the height you set. Choose the COB reflector optic (36°, EN-CY02-H) or the convex Fresnel optic (60–75°, EN-CY02-HF); honeycomb louvre is optional.
ModelPowerSize (mm)EN-CY02-H-69x1507 W / 12 WΦ69 × H150EN-CY02-H-69x2007 W / 12 W / 18 W / 24 WΦ69 × H200EN-CY02-H-83x1507 W / 12 W / 18 WΦ83 × H150EN-CY02-H-83x20018 W / 24 WΦ83 × H200EN-CY02-H-106x20024 W / 30 WΦ106 × H200EN-CY02-H-55x3007 W / 12 WΦ55 × H300EN-CY02-H-55x4007 W / 12 WΦ55 × H400LED140-150 lumens/watt gold-wire LM80 certified LED, CRI > 80 (90/96 upon request)DriverBIS-certified, HPF, THD < 10%, minimal ripple, 2.5–4 kV surge protection, OVP 440VOptional LEDsCree | Bridgelux | EdisonOptional DriversFulham | Osram | Philips- Application
- Hospitality, Retail, Premium residential, Office
- Power options
- 7 W, 12 W, 18 W, 24 W, 30 W (varies by size)
- Sizes
- Φ55 × H300 mm, Φ55 × H400 mm, Φ69 × H150 mm, Φ69 × H200 mm, Φ83 × H150 mm, Φ83 × H200 mm, Φ106 × H200 mm
- Body
- AL6063 aluminium
- Body finish
- Matte White, Matte Black
- Inner cup finishes
- Gunmetal Black, Light Gold, Rose Gold, Matte White, Matte Black
- Optic
- COB reflector cup (EN-CY02-H), Convex Fresnel (EN-CY02-HF), optional honeycomb louvre
- Beam angle
- 36° (COB), 60–75° (Fresnel)
- Source
- High-CRI COB (SMD with Fresnel optic)
- Mounting
- Hanging — supplied with 1.5 m canopy (current-carrying wire + ceiling plate)
- Surface version
- EN-CY02
- CCT options
- 2700K, 3000K, 4000K, 5000K
- CRI
- Ra ≥ 80 (90/96 on request)
- Driver
- Constant-current, DALI, 0–10V, Triac
- IP rating
- IP20 (indoor)
- Lifetime
- L80B10 ≥ 50,000 hours
- Operating voltage
- 220–240 V AC
- Surge protection
- 2.5–4 kV
Mounting
- Pendant
